What’s QD MLA
Combination of Micro Lens
Array and Quantum Dot layer
QD MLA component will help you
solve the difficulties in the bonding
process, the technical challenge for
colorization and the inefficiency
caused by complex modularization.
What is QD MLA ?
01
Quantum Dot Micro Lens Array
Minimize Optical Loss between MLA and QD
QD MLA is an optical component that combines Micro Lens Array (MLA) and Quantum Dot (QD) layer, that is the color conversion layer. MLA is the transparent material component that arranges lenses with a diameter of 1~3 ㎛ or smaller to realize 5,000 PPI or higher resolution. QD layer is the multi-layered part of transparent and nanomaterial to convert blue light of Micro LED into red or green. QD MLA is an innovative component that minimizes the optical loss that occurs when MLA and QD are bonded.
02
Make it Possible, New Platform
QD MLA Realizes Essential Resolution and Color
Augmented Reality (AR) & Virtual Reality (VR) glasses based on μ-LED light sources around the world are Monochrome
Color. AR & VR glasses based on OLED has very Low Resolution, does not produce enough Luminance to be used out
doors, and relatively higher power consumption than μ-LED. QD MLA enables VR & AR to become a new information
platform that will change the world we live in.
